HMK220 Doypack Packing Machine

Machine Introduction:

It is used to produce medium-sized flat bags and self-supporting bags.Different accessories can be selected to produce zipper bags,positive suction nozzle bags or side suction nozzle bags.On the basis of the lowest cost possible,it has a larger adjustment range,cost-effective.

The equipment is a horizontal form fill seal packing machine.Suitable for pet food,flavoured foods,dried fruit,candy.oatmeal,etc.

Features:

1.Automatic hole punch correction system for stand-up pouches.

2.Three different filling stations.

3.Independent electrical cabinet and independent unwinding system.

4.Cooling device for strengthen the top seal.

Machine Paramenters:

Type of machine: HMK220

Minimum bag size(mm): 70x120x20

Maximum bag size(mm): 90x250x45

Bag volume range: 1000ml

Film size range: Maximum diameter 400mm,core diameter 76mm or 152mm

Production speed: 50PPM

Power consumption: 15KW
